Product Summary

The 74HC86PW is a high-speed Si-gate CMOS device. It is pin compatible with low power Schottky TTL (LSTTL). The 74HC86PW is specified in compliance with JEDEC standard no. 7A. The 74HC86PW provides the EXCLUSIVE-OR function.

Parametrics

74HC86PW absolute maximum ratings: (1)tPHL/ tPLH, propagation delay nA, nB to nY: 11ns when CL = 15 pF; VCC = 5V; (2)CI, input capacitance: 3.5pF; (3)CPD, power dissipation capacitance per gate: 30pF.

Features

74HC86PW features: (1)Output capability: standard; (2)ICC category: SSI.

Diagrams

74HC86PW block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
74HC86PW,112
74HC86PW,112
NXP Semiconductors
Gates (AND / NAND / OR / NOR) QUAD 2-IN EX-OR GATE
Data Sheet
0-1: $0.24
1-25: $0.20
25-100: $0.16
100-250: $0.11
74HC86PW,118
74HC86PW,118
NXP Semiconductors
Gates (AND / NAND / OR / NOR) QUAD 2-INPUT EXCLSVE
Data Sheet
0-1: $0.07
1-25: $0.06
25-100: $0.06
100-250: $0.05
