Product Summary

The DS90C032TM is a quad CMOS differential line receiver designed for applications requiring ultra low power dissipation and high data rates. The DS90C032TM is designed to support data rates in excess of 155.5 Mbps (77.7 MHz) utilizing Low Voltage Differential Signaling (LVDS) technology. It accepts low voltage (350 mV) differential input signals and translates them to CMOS (TTL compatible) output levels.

Parametrics

DS90C032TM absolute maximum ratings: (1)Supply Voltage (VCC): 0.3V to +6V; (2)Input Voltage (RIN+, RIN.): 0.3V to (VCC +0.3V); (3)Enable Input Voltage (EN): 0.3V to (VCC +0.3V); (4)Output Voltage (ROUT): 0.3V to (VCC +0.3V); (5)Maximum Package Power Dissipation @ +25℃: M Package, 1025 mW;E Package, 1830 mW; (6)Derate M Package: 8.2 mW/℃ above +25℃; (7)Derate E Package: 12.2 mW/℃ above +25℃; (8)Storage Temperature Range: 65℃ to +150℃; (9)Lead Temperature Range Soldering (4 sec.): +260℃.

Features

DS90C032TM features: (1)>155.5 Mbps (77.7 MHz) switching rates; (2)Accepts small swing (350 mV) differential signal levels; (3)Ultra low power dissipation; (4)600 ps maximum differential skew (5V, 25℃); (5)6.0 ns maximum propagation delay; (6)Industrial operating temperature range; (7)Military operating temperature range option; (8)Available in surface mount packaging (SOIC) and (LCC); (9)Pin compatible with DS26C32A, MB570 (PECL) and 41LF (PECL); (10)Supports OPEN, short and terminated input fail-safe; (11)Compatible with IEEE 1596.3 SCI LVDS standard; (12)Conforms to ANSI/TIA/EIA-644 LVDS standard.
