LTC2495CUHF#TRPBF

ADC, 6V, 60Hz, QFN

Rated 5 Rating 5 | reviews | Write a review

Price:: US $4.00~4.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 2500 :	4.20 / Piece
2500 ~ 10000 :	4.10 / Piece
10000 ~ 250000 :	4.00 / Piece

PartNumber:: LTC2495CUHF#TRPBF

Brand:: Linear Technology - Linear | Pack: QFN | D/C: 11+

Availability:: Supply Ability: 4/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-16

From Other Seller

Part Number:LTC2495CUHF#TRPBF
US $4.00 - 4.20
Quantity:

piece

Product Summary

The LTC2495CUHF is a 16-channel (eight differential) , 16-bit, No Latency ΔΣADC with Easy Drive technology and a 2-wire, I2C interface. The LTC2495CUHF includes programmable gain, a high accuracy temperature sensor, and an integrated oscillator. The LTC2495CUHF allows a wide common mode input range (0V to VCC) , independent of the reference voltage. Applications of the LTC2495CUHF include: Direct Sensor Digitizer, Direct Temperature Measurement, Instrumentation and Industrial Process Control.

Parametrics

LTC2495CUHF absolute maximum ratings: (1) Supply Voltage (VCC) : -0.3 to (Vcc +0.3V) ; (2) Analog Input Voltage (CH0-CH15, COM) : -0.3 to (Vcc +0.3V) ; (3) REF+, REF–: -0.3 to (Vcc +0.3V) ; (4) ADCINN, ADCINP, MUXOUTP, MUXOUTN: -0.3 to (Vcc +0.3V) ; (5) Digital Input Voltage: -0.3 to (Vcc +0.3V) ; (6) Digital Output Voltage: -0.3 to (Vcc +0.3V) ; (7) Operating Temperature Range: 0 to 70°C; (8) Storage Temperature Range: -65 to 150°C.

Features

LTC2495CUHF features: Up to Eight Differential or 16 Single-Ended Inputs; (2) Easy DriveTechnology Enables Rail-to-Rail Inputs with Zero Differential Input Current; (3) Directly Digitizes High Impedance Sensors with Full Accuracy; (4) 2-Wire I2C Interface with 27 Addresses Plus One Global Address for Synchronization; (5) 600nV RMS Noise; (6) Programmable Gain from 1 to 256; (7) Integrated High Accuracy Temperature Sensor; (8) GND to VCC Input/Reference Common Mode Range; (9) Programmable 50Hz, 60Hz, or Simultaneous 50Hz/60Hz Rejection Mode; (10) 2ppm INL, No Missing Codes; (11) 1ppm Offset and 15ppm Full-Scale Error; (12) 2x Speed/Reduced Power Mode (15Hz Using Internal Oscillator and 80μA at 7.5Hz Output) ; (13) No Latency: Digital Filter Settles in a Single Cycle, Even After a New Channel is Selected; (14) Single Supply 2.7V to 5.5V Operation (0.8mW) ; (15) Internal Oscillator; (16) Tiny 5mm ×7mm QFN Package.
