S-3511AEFS

S-3511AEFS, CMOS real-time clock IC, SOP, -0.3 to 6.5V, 0.7mA, Silego Technology

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.20~1.40 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	1.40 / Piece
101 ~ 500 :	1.30 / Piece
501 ~ 10000 :	1.20 / Piece

PartNumber:: S-3511AEFS

Brand:: Silego Technology Inc. - Silego | Pack: SOP | D/C: 12+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-02-26

From Other Seller

Part Number:S-3511AEFS
US $1.20 - 1.40
Quantity:

piece

Product Summary

The S-3511AEFS is a CMOS real-time clock IC, which is designed to transfer or set each data of a clock and calender as requested by a CPU. It provides connection with a CPU via three wires and has an interrupt/alarm feature, allowing the alleviation of software treatment on the side of a host. The S-3511AEFS also works on lower power with the oscillating circuit operated at a constant voltage. Its package uses an extremely small and thin type of eight-pin SSOP. The applications of the S-3511AEFS include cellular phone, PHS, a variety of pagers, TV set and VCR, camera.

Parametrics

S-3511AEFS absolute maximum ratings: (1)Power voltage, VDD: -0.3 to 6.5V; (2)Input voltage, Vin: -0.3 to 6.5V; (3)Output voltage, Vout: -0.3 to 6.5V; (4)Operating temperature, Topr: -40 to 85℃; (5)Retention temperature, tstg: -55 to 125℃.

Features

S-3511AEFS features: (1)Low power consumption: 0.7μA typ; (2)Wide area of operating voltage: 1.7 to 5.5V; (3)SCD input/output of year, month, day, day of a week, hour, minute and second; (4)CPU interface via three wires; (5)Auto calender till the year of 2,099; (6)Built-in power voltage detecting circuit; (7)Built-in constant voltage circuit; (8)Built-in flag generating circuit on power on/off; (9)Built-in alarm interrupt; (10)Steady-state interrupt frequency/duty setting feature; (11)Built-in 32kHz crystal osillating circuit; (12)8-pin SSOP package.
