TLV320AC36CDW

TLV320AC36CDW, Voice-band audio processor, 5.5 V, 16 kHz, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.00~5.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 500 :	5.00 / Piece
501 ~ 1000 :	4.00 / Piece
1001 ~ 3000 :	3.00 / Piece

PartNumber:: TLV320AC36CDW

Brand:: Texas Instruments - TI | Pack: SOP | D/C: 13+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-13

From Other Seller

Part Number:TLV320AC36CDW
US $3.00 - 5.00
Quantity:

piece

Product Summary

The TLV320AC36CDW is a 3- V Voice-band audio processor. It is designed to perform the transmit encoding (A/D conversion) and receive decoding (D/A conversion) together with transmit and receive filtering for voice-band communications systems. Cellular telephone system is targeted in particular; however, the TLV320AC36CDW can function in other systems including digital audio, telecommunications, and data acquisition. The TLV320AC36CDW is pin-selectable for either of two modes, companded and linear, providing data in two formats. In the companded mode, data is transmitted and received in 8-bit words.

Parametrics

TLV320AC36CDW absolute maximum ratings: (1)Supply voltage range, VCC: –0.3 V to 5.5 V; (2)Output voltage range at DOUT, VO: –0.3 V to 5.5 V; (3)Input voltage range at DIN, VI: –0.3 V to 5.5 V; (4)Continuous total power dissipation: See Dissipation Rating Table; (5)Operating free-air temperature range: C suffix: 0℃ to 70℃; (6)Operating free-air temperature range: I suffix: –40℃ to 85℃; (7)Storage temperature range, Tstg: – 65℃ to 150℃; (8)Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: 260℃.

Features

TLV320AC36CDW features: (1)Single 3-V Operation; (2)Low Power Consumption:; (3)Combined A/D, D/A, and Filters; (4)Extended Variable-Frequency Operation; (5)Sample Rates up to 16 kHz; (6)Pass-Band up to 7.2 kHz; (7)Electret Microphone Bias Reference; (8)Voltage Available; (9)Drive a Piezo Speaker Directly; (10)Compatible With All Digital Signal Processors (DSPs).
