Product Summary
The TS1117CP33RO is a high performance positive voltage regulator designed for use in applications requiring low dropout performance at full rated current, Additionally, the TS1117CP33RO provides excellent regulation over variations due to changes in line, load and temperature. Outstanding features include low dropout performance at rated current, fast transient response, internal current limiting and thermal shutdown protection of the output device. The TS1117CP33RO is a three terminal regulators with fixed and adjustable voltage options available in popular packages. This series is offered in 3-pin TO-263, TO-220, TO-252 and SOT-223 package.
Parametrics
TS1117CP33RO absolute maximum ratings: (1)Input Supply Voltage, Vin: 12 V; (2)Operation Input Supply Voltage, Vin (operate): 7 V; (3)Power Dissipation, PD: Internally Limited W; (4)Operating Junction Temperature Range, TJ: -25 to +150℃; (5)Storage Temperature Range, TSTG: -65 to +150℃; (6)Lead Soldering Temperature (260℃), TO-220/TO-263 Package: 10S; TO-252/SOT-223 Package: 5S.
Features
TS1117CP33RO features: (1)Low dropout performance 1.3V max; (2)Full current rating over line and temperature; (3)Fast transient response; (4)±2%Total output regulation over line, load and temperature; (5)Adjust pin current max 90μA over temperature; (6)Line regulation typical 0.015%; (7)Load regulation typical 0.05%; (8)Fixed/adjustable output voltage; (9)TO-220, TO-263 TO-252 and SOT-223 package.
Diagrams
