Product Summary

The dd160kb120 is a Power Diode Module. The dd160kb120 is designed for various rectifier circuits. The dd160kb120 has two diode chips connected in series and the mounting base is electrically isolated from elements for simple heatsink construction. Wide voltage rating up to, 1600V is available for various input voltages.

Parametrics

dd160kb120 absolute maximum ratings: (1)VRRM, Repetitive Peak Reverse Voltage: 1200 V; (2)VRSM, Non-Repetitive Peak Reverse Voltage: 1300 V; (3)IF(AV), Average Forward Current: 160 A; (4)IF(RMS), R.M.S. Forward Current: 250 A; (5)IFSM, Surge Forward Current: 3200 A; (6)I2t: 42600 A2S; (7)Tj, Operating Junction Temperature: -40 to +150 ℃; (8)Tstg, Storage Temperature: -40 to +125 ℃; (9)VISO, Isolation Breakdown Voltage: 2500 V; (10)Mounting Torque: 4.7(48) Nm; (11)Mass, Typical Value: 170 g; (12)IRRM, Repetitive Peak Reverse Current, max.: 30 mA; (13)VFM, Forward Voltage Drop, max.: 1.35 V; (14)Rth(j-c), Thermal Impedance, max.: 0.3 ℃/W.

Features

dd160kb120 features: (1)Isolated mounting base; (2)Two elements in a package for simple bridge connections; (3)Highly reliable glass passivated chips; (4)High surge current capability; (5)Various rectifiers, Battery chargers, DC motor drives.
