Product Summary

The lti550hn02 is a color active matrix liquid crystal display that uses amorphous silicon TFT as switching components. The lti550hn02 is composed of a TFT LCD panel, a driver circuit and a back light unit. The resolution of a 55.0 is 1920 × 1080 and this model can display up to 16.7 Million colors with wide viewing angle of 89°or higher in all directions. This panel of the lti550hn02 is intended to support applications to provide a excellent performance for Flat Panel Display such as Home-alone Multimedia TFT-LCD TV, Display terminals for AV application products, and Digital Information Display.

Parametrics

lti550hn02 absolute maximum ratings: (1)Power Supply Voltage, VDD: 10.8 to 13.2 V; (2)Storage temperature, TSTG: -20 to 60 ℃; (3)Glass Surface temperature, Center Tcenter: 0 to 50 ℃; (4)Shock, XYZ: 30 G; (5)Vibration, VNOP: 1.5 G.

Features

lti550hn02 features: (1)RoHS compliance; (2)High contrast radio & aperture radio with wide color gamut; (3)SVA mode; (4)Wide viewing angle; (5)High speed response; (6)Landscape/Portrait type compatible; (7)FHD resolution; (8)Low Power consumption; (9)Direct Type 16 CCFLs; (10)DE mode; (11)2ch LVDS interface.

Diagrams

lti550hn02 block diagram
