Product Summary
The mc12015d is a dual 6-4 input parity checker. The mc12015d is primarily used in parity checking, parity generation and error detection and correction circuits.
Parametrics
mc12015d absolute maximum ratings: (1)Power Supply, VEE: -0.8 to 0 Vdc; (2)Input Voltage, VL: 0 to VEE Vdc; (3)Output Current-Continuous, LOUT: 50 mA; (4)Operating Temperature Range, TA: 0 to 75 ℃; (5)Storage Temperature Range, TSTG: -55 to 150 ℃.
Features
mc12015d features: (1)Propagation Delay, 1.5 ns Typical; (2)Improved Noise Margin 150 mV; (3)Voltage Compensated; (4)MECL 10 k-Compatible.
Diagrams
