MJ4035

mj4035, medium-power complementary silicon transistor, 100 V, 16 A, TO, Motorola, Inc

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.30~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 500 :	2.40 / Piece
501 ~ 1000 :	2.30 / Piece

PartNumber:: MJ4035

Brand:: Motorola, Inc - Motorola | Pack: | D/C:

Availability:: Supply Ability: 8000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-18

From Other Seller

Part Number:MJ4035
US $2.30 - 2.50
Quantity:

piece

Product Summary

The mj4035 is a medium-power complementary silicon transistor. The mj4035 designed for use as output devices in complementary general purpose amplifier applications.

Parametrics

mj4035 absolute maximum ratings: (1)Collector-Emitter Voltage, VCEO: 100 V; (2)Collector-Base Voltage, VCBO: 100 V; (3)Emitter-Base Voltage, VEBO: 5.0 V; (4)Collector Current-Continuous-Peak, LC: 16 A; (5)Base Current,LB: 0.5 A; (6)Total Power Dissipation, PD: 150 W, 0.857 W/℃; (7)Operating and Storage Junction Temperature Range, TJ, TSTG: -65 to +200 ℃.

Features

mj4035 features: (1)High Gain Darlington Performance; (2)DC Current Gain hFE = 3500 @ lc = 10 A; (3)Monolithic Construction with Built-in Base-Emitter Shunt Resistor.
