Product Summary

The my4z-02 100/110vac is a General-purpose Relay.

Parametrics

my4z-02 absolute maximum ratings: (1)Rated load: 5 A, 250 VAC; (2)Carry current: 10 A (see note); (3)Max. switching voltage: 250 VAC, 125 VDC; (4)Max. switching current: 10 A; (5)Max. switching capacity: 2,500 VA, 300 W; (6)Min. permissible load*: 5 VDC, 1 mA.

Features

my4z-02 features: (1)Models with lockable test buttons now available.; (2)Multiple features available, including operation indicators (mechanical and LED indicators), lockable test button, built-in diode and CR (surge suppression), bifurcated contacts, etc.; (3)Environment-friendly cadmium-free contacts.; (4)Wide range of Sockets (PY, PYF Series) and optional parts.; (5)Max. Switching Current: 2-pole: 10 A, 4-pole: 5 A; (6)Provided with nameplate.; (7)RoHS Complaint.

Diagrams

my4z-02 block diagram
