Product Summary
The tda9340ps/n3/a/1923 is an IC-bus controlled TV display processor. The tda9340ps/n3/a/1923 contains the following functions: RGB control processor with Y, U and V inputs; Programmable deflection processor with internal clock generation, which generates the drive signals for the horizontal, East-West (E-W) and vertical deflection; The circuit can be used in both single scan (50 or 60 Hz) and double scan (100 or 120 Hz) applications. The tda9340ps/n3/a/1923 has a multi-sync function for the horizontal PLL, with a frequency range from 30 to 50 kHz (2fH mode) or 15 to 25 kHz (1fH mode), so that the ICs can also be used to display SVGA signals.
Parametrics
tda9340ps/n3/a/1923 absolute maximum ratings: (1)VP, supply voltage: 9.0 V; (2)Tstg, storage temperature: -25 to +150 ℃; (3)Tamb, ambient temperature: 0 to 70 ℃; (4)Tsol, soldering temperature: 260 ℃; (5)Tj, junction temperature: 150 ℃.
Features
tda9340ps/n3/a/1923 features: (1)Can be used in both single scan (50 or 60 Hz) and double scan (100 or 120 Hz) applications; (2)YUV input and linear RGB input with fast blanking; (3)Separate OSD/text input with fast blanking or blending; (4)Black stretching of non-standard luminance signals; (5)Switchable matrix for the colour difference signals; (6)RGB control circuit with Continuous Cathode Calibration (CCC), plus white point and black level offset adjustment; (7)Blue stretch circuit which offsets colours near white towards blue; (8)Internal clock generation for the deflection processing, which is synchronized by a 12 MHz ceramic resonator oscillator; (9)Horizontal synchronization with two control loops and alignment-free horizontal oscillator; (10)Slow start and slow stop of the horizontal drive pulses; (11)Low-power start-up option for the horizontal drive circuit; (12)Vertical count-down circuit; (13)Vertical driver optimized for DC-coupled vertical output stages; (14)Vertical and horizontal geometry processing; (15)Horizontal and vertical zoom possibility and vertical scroll function for application with 16 : 9 picture tubes; (16)Horizontal parallelogram and bow correction; (17)IC-bus control of various functions; (18)Low dissipation.
Diagrams
