The 06fmn-bmt-a-tf(lf)(sn) is a Silicon N Channel MOS FET High Speed Power Switching.
Parametrics
06fmn-bmt-a-tf(lf)(sn) absolute maximum ratings: (1)Drain to source voltage VDSS: 500 V; (2)Gate to source voltage VGSS: ±30 V; (3)Drain current ID: 3 A; (4)Drain peak current ID (pulse)Note 1: 12 A; (5)Body-drain diode reverse drain current IDR: 3 A; (6)Body-drain diode reverse drain peak current IDR (pulse)Note 1 12 A Avalanche current IAP Note 3: 3 A; (7)Channel dissipation Pch Note 2: 25 W; (8)Channel to case thermal Impedance θ ch-c: 5.0 °C/W; (9)Channel temperature Tch: 150 °C; (10)Storage temperature Tstg: –55 to +150 °C.
Features
06fmn-bmt-a-tf(lf)(sn) features: (1)Low on-resistance: R DS (on)= 2.5Ω typ.; (2)Low leakage current: IDSS = 1 μA max (at VDS = 500 V); (3)High speed switching: tf = 15 ns typ (at VGS = 10 V, VDD = 250 V, ID = 1.5 A); (4)Low gate charge: Qg = 14 nC typ (at VDD = 400 V, VGS = 10 V, ID = 3 A); (5)Avalanche ratings.
