2SC2879

2SC2879, transistor, 45 V, 250 W, 25 A

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.30~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 500 :	2.40 / Piece
501 ~ 1000 :	2.30 / Piece

PartNumber:: 2SC2879

Brand:: Toshiba Semiconductor - Toshiba | Pack: | D/C:

Availability:: Supply Ability: 8000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-10-21

From Other Seller

Part Number:2SC2879
US $2.30 - 2.50
Quantity:

piece

Product Summary

The 2sc2879 is a transistor which has 2~30MHz SSB linear power amplifier applications. The 2sc2879 has the low supply voltage use.

Parametrics

2sc2879 absolute maximum ratings: (1)Collector-Base Voltage: 45 V ; (2)Collector-Emitter Voltage: 45 V ; (3)Collector-Emitter Voltage: 18 V ; (4)Emitter-Base Voltage: 4 V ; (5)Collector Current: 25 A ; (6)Collector Power Dissipation: 250 W ; (7)Junction Temperature: 175°C; (8)Storage Temperature Range Tstg: -65~175°C.

Features

2sc2879 features: (1)Specified 12.5V, 28MHz Characteristics ; (2)Output Power : Po = 100WPEP; (3)Power Gain : Gp = 13dB ; (4)Collector Efficiency : ηC = 35% (Min.) ; (5)Intermodulation Distortion : IMD =-24dB(Max.).
