2SC4582

2sc4582, Switching Power Transistor, 600 V, 15 A, ITO, Sanyo Semicon Device

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.30~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 500 :	2.40 / Piece
501 ~ 1000 :	2.30 / Piece

PartNumber:: 2SC4582

Brand:: Sanyo Semicon Device - SANYO | Pack: | D/C:

Availability:: Supply Ability: 8000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-18

From Other Seller

Part Number:2SC4582
US $2.30 - 2.50
Quantity:

piece

Product Summary

The 2sc4582 is a Switching Power Transistor.

Parametrics

2sc4582 absolute maximum ratings: (1)Storage Temperature, Tstg: -55 to 150 ℃; (2)Junction Temperature, Tj: 150 ℃; (3)Collector to Base Voltage, VCBO: 600 V; (4)Collector to Emitter Voltage, VCEO: 450 V; (5)Emitter to Base Voltage, VEBO: 7 V; (6)Collector Current DC, IC: 15 A; (7)Collector Current Peak, ICP: 30 A; (8)Base Current DC, IB: 6 A; (9)Base Current Peak, IBP: 12 A; (10)Total Transistor Dissipation, PT: 75 W; (11)Dielectric Strength, Vdis: 2 kV; (12)Mounting Torque, TOR: Nm.

Features

2sc4582 features: (1)Collector to Emitter Sustaining Voltage, VCEO(sus): Min 450 V; (2)Collector Cutoff Current, ICBO: Max 0.1 mA; (3)Emitter Cutoff Current, IEBO: Max 0.1 mA; (4)DC Current Gain, hFE: Min 10 mA; (5)Collector to Emitter Saturation Voltage, VCE(sat): Max 1.0 V; (6)Base to Emitter Saturation Voltage, VBE(sat): Max 1.5 V; (7)Thermal Resistance, θjc: Max 1.67 ℃/W; (8)Transition Frequency, fT: STD 20 MHz; (9)Turn on Time, ton: Max 0.5 μs; (10)Storage Time, ts: Max 2.0 μs; (11)Fall Time, tf: Max 0.2 μs.
