Product Summary

The 74hc08d is a Quad 2-input AND gate. The 74hc08d is high-speed Si-gate CMOS device and is pin compatible with low power Schottky TTL (LSTTL). The 74hc08d is specified in compliance with JEDEC standard no. 7A. The 74hc08d provides the 2-input AND function.

Parametrics

74hc08d absolute maximum ratings: (1)VCC, supply voltage: 2.0 to 6.0 V; (2)VI, input voltage: 0 to VCC; (3)VO, output voltage: 0 to VCC; (4)Tamb, ambient temperature: -40 to +125 ℃; (5)tr,tf, input rise and fall times: 1000 ns.

Features

74hc08d features: (1)Complies with JEDEC standard no. 8-1A; (2)ESD protection: HBM EIA/JESD22-A114-A exceeds 2000 V, MM EIA/JESD22-A115-A exceeds 200 V.; (3)Specified from -40 to +85 ℃ and -40 to +125 ℃.

Diagrams

74hc08d block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
74HC08D,652
74HC08D,652
NXP Semiconductors
Gates (AND / NAND / OR / NOR) QUAD 2-IN AND GATE
Data Sheet
0-1: $0.05
1-25: $0.05
25-100: $0.05
100-250: $0.04
74HC08D,653
74HC08D,653
NXP Semiconductors
Gates (AND / NAND / OR / NOR) QUAD 2-INPUT AND GATE
Data Sheet
0-1: $0.05
1-25: $0.05
25-100: $0.05
100-250: $0.04
74HC08DB,112
74HC08DB,112
NXP Semiconductors
Gates (AND / NAND / OR / NOR) QUAD 2-IN AND GATE
Data Sheet
0-1: $0.13
1-25: $0.11
25-100: $0.11
100-250: $0.10
74HC08DB,118
74HC08DB,118
NXP Semiconductors
Gates (AND / NAND / OR / NOR) QUAD 2-INPUT AND GATE
Data Sheet
0-1: $0.13
1-25: $0.11
25-100: $0.11
100-250: $0.10
74HC08DR2G
74HC08DR2G
ON Semiconductor
Gates (AND / NAND / OR / NOR) QUAD 2 INPT AND GATE
Data Sheet
0-1: $0.26
1-25: $0.17
25-100: $0.14
100-500: $0.09
74HC08DTR2G
74HC08DTR2G

IC GATE AND QUAD 2INPUT 14-TSSOP
Data Sheet
0-1: $0.29
1-10: $0.21
10-25: $0.17
25-100: $0.14
100-250: $0.10
250-500: $0.08
500-1000: $0.06
