Product Summary

The AT27C512R-70PU is a low-power, high-performance 524,288-bit one-time programma-ble read-only memory (OTP EPROM) organized 64K by 8 bits. The AT27C512R-70PU requires only one 5V power supply in normal read mode operation. Any byte can be accessed in less than45 ns, eliminating the need for speed reducing WAIT states on high-performancemicroprocessor systems. Atmel’s scaled CMOS technology provides high-speed, lower active power consumption, and significantly faster programming. Power consumption is typically only 8 mA in Active Mode and less than 10 μA in Standby.

Parametrics

AT27C512R-70PU absolute maximum ratings: (1)Temperature Under Bias: -55℃ to +125℃; (2)Storage Temperature: -65℃ to +150℃; (3)Voltage on Any Pin with Respect to Ground: -2.0V to +7.0V; (4)Voltage on A9 with Respect to Ground: -2.0V to +14.0V; (5)VPP Supply Voltage with Respect to Ground: -2.0V to +14.0V.

Features

AT27C512R-70PU features: (1)Fast Read Access Time-45 ns; (2)Low-Power CMOS Operation:100 μA Max Standby; 20 mA Max Active at 5 MHz; (3)JEDEC Standard Packages: 28-lead PDIP; 32-lead PLCC; 28-lead TSOP and SOIC; (4)5V ± 10% Supply; (5)High-Reliability CMOS Technology: 2,000V ESD Protection; 200 mA Latchup Immunity; (6)Rapid Programming Algorithm-100 μs/Byte (Typical); (7)CMOS and TTL Compatible Inputs and Outputs; (8)Integrated Product Identification Code; (9)Industrial and Automotive Temperature Ranges; (10)Green (Pb/Halide-free) Packaging Option.
