Product Summary
The BU4052BCFV-E2 is an analog selectable composite multiplexer/demultiplexer. The BU4052BCFV-E2 is configured with two 4 channels, and switches applicable for each channel are turned on according to digital signals of control terminal. Even if the logic amplitude (VDD-VSS) of the control signal is small, signals of large amplitude (VDD-VEE) can be switched.
Parametrics
BU4052BCFV-E2 absolute maximum ratings: (1)Power Supply Voltage, VDD: -0.5 to 20V; (2)Supply current, Iin: ±10mA; (3)Operating temperature, Topr: -40 to 85℃; (4)Storage temperature, Tstg: -55 to 150℃; (5)Input Voltage, VIN: -0.5 to VDD +0.5V; (6)Maximum junction temperature, Tjmax: 150℃.
Features
BU4052BCFV-E2 features: (1)Low power consumption; (2)Wide operating supply voltage (3V to 18V); (3)High input impedance; (4)L-TTL2 input and LS-TTL1 can be driven directly; (5)Applicable channel switches can be turned “ON” and “OFF” by the digital control signal; (6)Small control voltage (VDD-VSS) can control signals of large amplitude (VDD-VEE); (7)Linearity with excellent transfer characteristics.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 BU4052BCFV-E2 |
ROHM Semiconductor |
Multiplexer Switch ICs DUAL 4 CH ANALOG MULTIPLEXER |
Data Sheet |
|
|
||||||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||||||
 |
BU4000B |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
 |
BU4001B |
ROHM Semiconductor |
Gates (AND / NAND / OR / NOR) QUAD 2INPUT NOR GATE |
Data Sheet |
|
|
||||||||||||
|
BU4001BF |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
 |
BU4001BF-E2 |
|
IC QUAD 2INPUT NORGATE SOP14 TR |
Data Sheet |
|
|
||||||||||||
 |
BU4011B |
ROHM Semiconductor |
Gates (AND / NAND / OR / NOR) QUAD 2INPUT NAND GATE |
Data Sheet |
|
|
||||||||||||
|
BU4011BF |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
