Product Summary

The ESJA53-20 is a High Voltage Silicon Diode.

Parametrics

ESJA53-20 absolute maximum ratings: (1)Repetitive peak reverse voltage: 20kVpeak; (2)Non-Repetitive peak forward current: 0.5 Apeak; (3)Average forward current: 5mA; (4)Allowable junction temperature: 120℃; (5)Storage temperature range: -40 to 120℃; (6)Allowable operating case temperature: 100℃.

Features

ESJA53-20 features: (1)5mA Average forward current; (2)75V Maximum forward voltage drop.

Diagrams

ESJA53-20 block diagram
