Product Summary

The GT28F008B3T90 is a 3V Advanced Boot Block Flash Memory. Intel provides the most flexible voltage solution in the flash industry, providing three discrete voltage supply pins: VCC for read operation, VCCQ for output swing, and VPP for program and erase operation. The GT28F008B3T90 provides program/erase capability at 2.7 V or 12 V (for fast production programming) and read with VCC at 2.7 V. Since many designs read from the flash memory a large percentage of the time, 2.7 V VCC operation can provide substantial power savings.

Parametrics

GT28F008B3T90 absolute maximum ratings: (1)Extended Operating Temperature During Read: -40℃ to +85℃; (2)During Block Erase and Program: -40℃ to +85℃; (3)Temperature under Bias: -40℃ to +85℃; (4)Storage Temperature: -65℃ to +125℃; (5)Voltage On Any Pin (except VCC, VCCQ and VPP) with Respect to GND: -0.5 V to +3.7 V; (6)VPP Voltage (for Block Erase and Program) with Respect to GND: -0.5 V to +13.5 V; (7)VCC and VCCQ Supply Voltage with Respect to GND: -0.2 V to +3.7 V; (8)Output Short Circuit Current: 100 mA.

Features

GT28F008B3T90 features: (1)Enhanced blocking for easy segmentation of code and data or additional design flexibility; (2)Program Suspend to Read command; (3)VCCQ input of 1.65 V?.5 V on all I/Os. See Figures 1 through 4 for pinout diagrams and VCCQ location; (4)Maximum program and erase time specification for improved data storage.
