Product Summary

The LM833 is a standard low–cost monolithic dual general–purpose operational amplifier employing Bipolar technology with innovative high–performance concepts for audio systems applications. The LM833 is specified over the automotive temperature range and is available in the plastic DIP and SO–8 packages (P and D suffixes). For an improved performance dual/quad version, see the MC33079 family.

Parametrics

LM833 features: (1)Low Voltage Noise: 4.5 nV/ Hz; (2)High Gain Bandwidth Product: 15 MHz; (3)High Slew Rate: 7.0 V/µs; (4)Low Input Offset Voltage: 0.3 mV; (5)Low T.C. of Input Offset Voltage: 2.0 µV/°C; (6)Low Distortion: 0.002%; (7)Excellent Frequency Stability; (8)Dual Supply Operatio.

Features

LM833 absolute maximum ratings: (1)Supply Voltage (VCC to VEE)VS: +36 V; (2)Input Differential Voltage Range (Note 1)VIDR: 30 V; (3)Input Voltage Range (Note 1)VIR: ±15 V; (4)Output Short Circuit Duration (Note 2)tSC: Indefinite; (5)Operating Ambient Temperature Range TA: –40 to +85 °C; (6)Operating Junction Temperature TJ: +150 °C; (7)Storage Temperature Tstg: –60 to +150 °C; (8)Maximum Power Dissipation (Notes 2 and 3)PD: 500 mW.

Diagrams

LM833 pin connection
