Product Summary

The MC1403PI is a precision band-gap voltage reference designed for critical instrumentation and D/A converter applications. This unit is designed to work with D/A converters, up to 12 bits in accuracy, or as a reference for power supply applications. The applications of the MC1403PI include: (1)Voltage Reference for 8 to 12 Bit D/A Converters; (2)Low TC Zener Replacement; (3)High Stability Current Reference; (4)Voltmeter System Reference; (5)Pb-Free Package is Available.

Parametrics

MC1403PI absolute maximum ratings: (1)Input Voltage, VI: 40 V; (2)Storage Temperature, Tstg: -65 to 150 ℃; (3)Junction Temperature, TJ: +175 ℃; (4)Operating Ambient Temperature Range, TA: 0 to +70 ℃.

Features

MC1403PI features: (1)Output Voltage: 2.5 V ± 25 mV; (2)Input Voltage Range: 4.5 V to 40 V; (3)Quiescent Current: 1.2 mA Typical; (4)Output Current: 10 mA; (5)Temperature Coefficient: 10 ppm/℃ Typical; (6)Guaranteed Temperature Drift Specification; (7)Equivalent to AD580; (8)Standard 8-Pin DIP, and 8-Pin SOIC Package.

Diagrams

MC1403PI pin connection
