Product Summary
The MIW5032 is a DC/DC converter.
Parametrics
MIW5032 absolute maximum ratings: (1)Input surge voltage ( 1000 ms ): 12VDC input models: -0.7 to 25 VDC; 24VDC input models: -0.7 to 50 VDC; 48VDC input models: -0.7 to 100 VDC; (2)Lead temperature (1.5mm from case for 10 Sec.): 260 ℃; (3)Internal power dissipation: 2,500 mW.
Features
MIW5032 features: (1)High efficiency up to 88%; (2)UL 94V-0 package material; (3)Industry standard pinout; (4)Over voltage protection; (5)Complies with EN55022 class A; (6)CSA1950 safety approval; (7)2:1 Wide input range; (8)MTBF > 1,000,000 hours; (9)1500VDC isolation; (10)Internal SMD construction.
Diagrams
