Product Summary
The ad3804-02 is a High Speed, Low Drift FET Operational Amplifier.
Parametrics
ad3804-02 absolute maximum ratings: (1)positive supply voltage: 18V; (2)negative supply voltage: -18V; (3)differential input signal: ±2*VS; (4)output short circuit current to ground: 80mA or 20mA; (5)junction temperature: +175°C; (6)storage temperature: -65 to +150°C; (7)lead temperature(soldering 10sec): +300°C.
Features
ad3804-02 features: (1)inpu offset voltage: 2.0mV; (2)output short circuit current: 90mA; (3)input bias current: 100mA; (4)operating power supply: ±6V.
Diagrams
