AT83C21GC144-ICSUL

GemCore Serial Lite PRO, SSOP24, -0.5 V to + 6.0 V, ATMEL Corporation

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.20~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 800 :	2.40 / Piece
801 ~ 1600 :	2.20 / Piece

PartNumber:: AT83C21GC144-ICSUL

Brand:: ATMEL Corporation - ATMEL | Pack: | D/C:

Availability:: Supply Ability: 8000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-23

From Other Seller

Part Number:AT83C21GC144-ICSUL
US $2.20 - 2.50
Quantity:

piece

Product Summary

The at83c21gc144-icsul is a GemCore Serial Lite PRO designed to simplify the integration of smart card interfaces in electronic devices. The at83c21gc144-icsul manages the electrical interface and communication with ISO 7816 –1/2/3/4 compatible smart cards and memory cards. The connection with the host processor is achieved via a serial asynchronous link; the rate can be selected from a range from 1200 to 115,200 bps.The software inside the GemCore chip handles a communication protocol with the host system called the Gemplus Block Protocol (GBP).A GBP Interface Library Kit can be provided, upon request. The at83c21gc144-icsul consists of the source code of the GBP communication layer between the host and GemCore. It is written in the C language. ,

Parametrics

at83c21gc144-icsul absolute maximum ratings: (1)Ambient Temperature Under Bias: -25°C to +85°C; (2)Storage Temperature: -65°C to + 150°C; (3)Voltage on VCC to VSS: -0.5 V to + 6.0 V; (4)Voltage on Any Pin to V: -0.5 V to V + 0.5 V.

Features

at83c21gc144-icsul features: (1)Number of smart cards supported = 1; (2)Asynchronous cards, T=0, T=1; (3)Synchronous/memory cards using a command interpreter; (4)EMV or non-EMV cards; (5)9.6 Kbps to 115 Kbps; (6)Card power supply: 1.8V/3V/5V; (7)ESD protection on card pins: 4 KV - human body model; (8)Card presence or insertion detection; (9)Short circuit current limitation.
