DG412DJ

dg412dj, 16-Pin DIP, Silan Microelectronics Joint-stock, monolithic quad analog switch, 44V, 30 mA, 470mW

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.30~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 500 :	2.40 / Piece
501 ~ 1000 :	2.30 / Piece

PartNumber:: DG412DJ

Brand:: Silan Microelectronics Joint-stock - Silan | Pack: | D/C:

Availability:: Supply Ability: 8000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-10-21

From Other Seller

Part Number:DG412DJ
US $2.30 - 2.50
Quantity:

piece

Product Summary

The dg412dj is a monolithic quad analog switch which was designed to provide high speed, low error switching of precision analog signals. Combining low power (0.35 μW) with high speed (tON: 110 ns), the dg412dj is ideally suited for portable and battery powered industrial and military applications. To achieve high-voltage ratings and superior switching performance, the dg412dj was built on Vishay Siliconix’s high voltage silicon gate process. An epitaxial layer prevents latchup. The dg412dj conducts equally well in both directions when on, and blocks input voltages up to the supply levels when off. The dg412dj responds to opposite control logic as shown in the Truth Table.

Parametrics

dg412dj absolute maximum ratings: (1)V+ to V-: 44V; (2)GND to V-: 25V; (3)VL: (GND - 0.3) to (V+) + 0.3V; (4)Digital Inputs a, VS, VD: (V-) -2V to (V+) + 2V or 30 mA, whichever occurs first; (5)Continuous Current (Any Terminal): 30mA; (6)Peak Current, S or D (Pulsed at 1 ms, 10 % duty cycle): 100mA; (7)Storage Temperature (AK, AZ Suffix): - 65 to 150℃; (8)Storage Temperature (DJ, DY Suffix): - 65 to 125℃; (9)Power Dissipation (Package) 16-Pin Plastic DIP: 470mW.

Features

dg412dj features: (1)44 V Supply Max Rating; (2)±15 V Analog Signal Range; (3)On-Resistance - rDS(on): 25Ω; (4)Fast Switching - tON: 110 ns; (5)Ultra Low Power - PD: 0.35μW; (6)TTL, CMOS Compatible; (7)Single Supply Capability; (8)Widest Dynamic Range; (9)Low Signal Errors and Distortion; (10)Break-Before-Make Switching Action; (11)Simple Interfacing.
