Product Summary
The el6270c is a Laser Driver with Ocillator and APC. The applications of the el6270c are DVD-RAM high speed drives, CD-RW applications, Writable optical drives, Laser diode current switching. A disable function is included which reduces supply current to less than 5uA.
Parametrics
el6270c absolute maximum ratings: (1)Oscillator to 500 MHz; (2)Oscillator to 100 mA pk/pk; (3)Single +5V supply (±10%); (4)temperature: 0 to +70°C.
Features
el6270c features: (1)Low output noise = 4.0nA/rt-Hz; (2)High-performance laser diode driver; (3)Pin compatible with EL6257; (4)Voltage-controlled output current source to 150 mA per channel, requiring one external set resistor per channel; (5)Current-controlled output current source to 150 mA per channel; (6)Rise time = 1.0 ns; (7)Fall time = 1.1 ns.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 EL6270C |
Other |
|
Data Sheet |
Negotiable |
|
||||
