Product Summary

The fmb-461f/es is an EMI filter module which has been specifically designed to reduce the input line reflected ripple current of Interpoint’s MTO, MTW, MHE, MLP, and MFW Series of DC/DC converters. It is intended for use in applications of high frequency (100 kHz) switch-mode DC/DC converters which must meet MIL-STD-461C levels of conducted power line noise. The fmb-461f/es is built using thick-film hybrid technology and is sealed in metal packages for military, aerospace, and other highreliability applications.

Parametrics

fmb-461f/es absolute maximum ratings: (1)Input Voltage: 0 to 40 VDC continuous; (2)Lead Soldering Temperature (10 sec per lead): 300℃; (3)Storage Temperature Range (Case): -55℃ to +135℃; (4)Isolation: 100 megohm minimum at 500 V, Any pin to case (except case pin).

Features

fmb-461f/es features: (1)-55℃ to +85℃ operation; (2)0 to 40 VDC volt input; (3)Up to 40 dB attenuation 110 kHz to 50 MHz; (4)Transient suppression; (5)Compliant to MIL-STD-461C, CE03.

Diagrams

fmb-461f/es block diagram
