Product Summary

The g084sn05 v7 is an 8.4 inch color TFT LCD module. The g084sn05 v7 is designed for display units for Industrial Applications.

Parametrics

g084sn05 v7 absolute maximum ratings: (1)Logic/LCD Drive Voltage, Vin: -0.3 to +3.6 Volt; (2)Input Voltage of Signal, Vin: -0.3 to VDD+0.3 Volt; (3)CCFL Current, ICFL: 4 to 7 mArms; (4)CCFL lgnition Voltage, Vs: 650 Vrms.

Features

g084sn05 v7 features: (1)VDD, Logic/LCD Drive Voltage: 3.0 to 3.6 Volt; (2)IDD, VDD Current: 300 to 330 mA; (3)Irush, LCD Inrush Current: 3 A; (4)PDD, VDD Power: 1 to 1.2 Watt.

Diagrams

g084sn05 v7 block diagram
