LM317LILPR

adjustable 3-terminal positive voltage regulator, SOP-8, 37V, 100mA, 40V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.20~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 800 :	2.40 / Piece
801 ~ 1600 :	2.20 / Piece

PartNumber:: LM317LILPR

Brand:: Texas Instruments - TI | Pack: | D/C:

Availability:: Supply Ability: 8000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-23

From Other Seller

Part Number:LM317LILPR
US $2.20 - 2.50
Quantity:

piece

Product Summary

The lm317lilpr is an adjustable 3-terminal positive voltage regulator capable of supplying in excess of 100mA over an output voltage range of 1.2 V to 37 V. This voltage regulator is exceptionally easy to use and requires only two external resistors to set the output voltage. Further, it employs internal current limiting; thermal shutdown and safe area compensation, making them essentially blow-out proof. The lm317lilpr serves a wide variety of applications including local, on card regulation. The lm317lilpr can also be used to make a programmable output regulator, or by connecting a fixed resistor between the adjustment and output, the LM317L can be used as a precision current regulator.

Parametrics

lm317lilpr absolute maximum ratings: (1)Input-Output Voltage Differential, VI-VO: 40Vdc; (2)Power Dissipation, PD: Internally Limited W; (3)Operating Junction Temperature Range, TJ: -40 to +125℃; (4)Storage Temperature Range, Tstg: -65 to +150℃.

Features

lm317lilpr features: (1)Pb-Free Packages are Available; (2)Output Current in Excess of 100mA; (3)Output Adjustable Between 1.2V and 37V; (4)Internal Thermal Overload Protection; (5)Internal Short Circuit Current Limiting; (6)Output Transistor Safe-Area Compensation; (7)Floating Operation for High Voltage Applications; (8)Standard 3-Lead Transistor Package; (9)Eliminates Stocking Many Fixed Voltages.
