MAX3509EUP

programmable power amplifier, -0.3V to +10.0V, 20-Pin TSSOP-EP, 2200mW

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.20~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 800 :	2.40 / Piece
801 ~ 1600 :	2.20 / Piece

PartNumber:: MAX3509EUP

Brand:: Dallas Semiconductor - Maxim | Pack: | D/C:

Availability:: Supply Ability: 8000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-23

From Other Seller

Part Number:MAX3509EUP
US $2.20 - 2.50
Quantity:

piece

Product Summary

The max3509eup is a programmable power amplifier for use in CATV upstream applications. The device outputs up to 66dBmV QPSK through a 1:1 transformer. It features variable gain controlled by a 3-wire digital serial bus. Gain control is available in 1dB steps. The max3509eup operates over a 5MHz to 65MHz frequency range. The max3509eup offers a transmit-disable mode, which places the device in a high-isolation state for use between bursts in TDMA systems. In this mode, all analog functions are shut down, minimizing output noise and power consumption. When entering and leaving transmit-disable mode, transients are kept to 25mV nominal at full gain. In addition, supply current is reduced to 7.8mA. The applications of the max3509eup are (1)Telephony-Over-Cable; (2)CATV Status Monitors; (3)OPENCATV Set-Top Boxes; (4)CATV Infrastructures; (5)Cable Modems.

Parametrics

max3509eup absolute maximum ratings: (1)VCC1, VCC2 to GND, GND1: -0.3V to +10.0V; (2)SCLK, SDA, CS, TXEN, SHDN to GND and GND1: -0.3V to +5.5V; (3)Continuous Input Voltage (IN+, IN-): 2VP-P; (4)Continuous Current (OUT+, OUT-): 80mA; (5)Continuous Power Dissipation (TA = +70°C), 20-Pin TSSOP-EP (derate at 27mW/°C above +70°C): 2200mW; (6)Operating Temperature Range: -40°C to +85°C; (7)Junction Temperature: +150°C; (8)Storage Temperature Range: -65°C to +150°C; (9)Lead Temperature (soldering, 10s): +300°C.
