Product Summary
The mqe9pd-1880-t7 single-port 10/100 mbps phy transceiver is an ieee compliant fastethernet phy transceiver that directly supports both 100base-tx and 10base-t applications. itprovides a media independent interface (mii) for easy attachment to 10/100 media accesscontrollers (macs). both full and half-duplex operation at 10 mbps and 100 mbps is supported.operation mode can be set to auto-negotiation, parallel detection, or manual control. the device ispowered from a single 3.3v power supply. It is ideal for: (1)combination 10base-t/100base-tx network interface cards (nics); (2)wireless access points; (3)network printers; (4)10/100 personal computer memory card international association (pcmcia)cards; (5)cable modems and set-top boxes.
Parametrics
mqe9pd-1880-t7 absolute maximum ratings: (1)recommended operating temperature topa: 0 to 70°C; (2)recommended supply voltage2 - analog and digital vcca, vccd: 3.14 to 3.45 v; (3)recommended supply voltage2 - i/o vccio: 2.35 to 3.45 v; (4)vcc current - 100 base-tx icc: 92 to 110 ma; (5)vcc current - 10 base-t icc: 66 to 82 ma; (6)hard power down icc: 1 ma; (7)soft power down icc: 51ma; (8)auto-negotiation icc: 90 to 110 ma.
Features
mqe9pd-1880-t7 features: (1)3.3V Operation; (2)IEEE 802.3-compliant 10BASE-T or 100BASE-TX with integrated filters; (3)Auto-negotiation and parallel detection; (4)MII interface with extended register capability; (5)Robust baseline wander correction; (6)Carrier Sense Multiple Access / Collision Detection (CSMA/CD)or full-duplex operation; (7)JTAG boundary scan; (8)MDIO serial port or hardware pin configurable; (9)Integrated, programmable LED drivers; (10)48-pin Low-profile Quad Flat Package.
Diagrams
