Product Summary

The mt1308e is a T-1 3/4 LED lamp with standoffs.

Parametrics

mt1308e absolute maximum ratings: (1)Forward current: 25 mA; (2)Reverse voltage: 4 V; (3)Power dissipation: 100 mW; (4)Operating temperature: -20 to 75 ℃; (5)Storage temperature: -30 to 100 ℃.

Features

mt1308e features: (1)Excellent on/off contrast radio; (2)Standoffs provide protection to LED die when used in solder bath; (3)Capable of pulse operation; (4)Secial brightness and wavelength sorting is available.

Diagrams

mt1308e block diagram
