OPA128SM

OPA128SM, TO-99, difet electrometer-grade operational amplifier, 500mW, ±18VDC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.30~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 500 :	2.40 / Piece
501 ~ 1000 :	2.30 / Piece

PartNumber:: OPA128SM

Brand:: Texas Instruments - TI | Pack: | D/C:

Availability:: Supply Ability: 8000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-10-21

From Other Seller

Part Number:OPA128SM
US $2.30 - 2.50
Quantity:

piece

Product Summary

The opa128sm is an ultra-low bias current monolithic operational amplifier. Using advanced geometry dielectrically-isolated FET inputs, this monolithic amplifier achieves a performance level exceeding even the best hybrid electrometer amplifiers. Laser-trimmed thin-film resistors give outstanding voltage offset and drift performance. A noise-free cascode and low-noise processing give the opa128sm excellent low-level signal handling capabilities. Flicker noise is very low. The opa128sm is an improved pin-for-pin replacement for the AD515. The opa128sm can be used in electrometer, mass spectrometer, chromatograph, ion gauge photodetector, and radiation-hard equipment.

Parametrics

opa128sm absolute maximum ratings: (1)Supply: ±18VDC; (2)Internal Power Dissipation: 500mW; (3)Differential Input Voltage: ±36VDC; (4)Input Voltage Range: ±18VDC; (5)Storage Temperature Range: –65°C to +150°C; (6)Operating Temperature Range: –55°C to +125°C; (7)Lead Temperature (soldering, 10s): +300°C; (8)Junction Temperature: +175°C.

Features

opa128sm features: (1)ultra-low bias current: 75fA max; (2)low offset: 500μV max; (3)low drift: 5μV/°C max; (4)high open-loop gain: 110dB min; (5)high common-mode rejection: 90dB min; (6)improved replacement for AD515 and AD549.
