Product Summary

The r5408n185kh-tr-f is a 310.00 MHz One Port SAW Resonator.

Parametrics

r5408n185kh-tr-f absolute maximum ratings: (1)CW RF Power Dissipation, P: 0 dBm; (2)DC Voltage, VDC: ±30 V; (3)Operating Temperature Range, TA: -10 to +60 ℃; (4)Storage Temperature Range, Tstg: -40 to +85 ℃.

Features

r5408n185kh-tr-f features: (1)Ideal for 310.00 MHz Transmitters; (2)Very Low Insertion Loss; (3)Quartz Stability; (4)Ultra Miniature Ceramic SMD Package (QCC4A).

Diagrams

r5408n185kh-tr-f block diagram
