RA03M4547MD

RA03M4547MD, output RF MOSFET Amplifier Module, 450 to 470 MHZ, -25 DBC, MITSUBISHI Electronics

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.20~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 800 :	2.40 / Piece
801 ~ 1600 :	2.20 / Piece

PartNumber:: RA03M4547MD

Brand:: Mitsumi Electronics, Corp. - Mitsumi | Pack: | D/C:

Availability:: Supply Ability: 8000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-23

From Other Seller

Part Number:RA03M4547MD
US $2.20 - 2.50
Quantity:

piece

Product Summary

The RA03M4547MD is a 38 dBm output RF MOSFET Amplifier Module for 7.2 volt portable radios that operate in the 450 to 470 MHz range.

Parametrics

RA03M4547MD absolute maximum ratings: (1)Frequency Range: 450 to 470 MHZ; (2)Output Power: 38 DBM; (3)Total Efficiency: 34 %; (4)2nd Harmonic: -25 DBC; (5)Input VSWR: 4.4; (6)Gate Current: 1 MA; (7)3rd Inter Modulation: -25 DBC; (8)Distortion: -25 DBC; (9)5th Inter Modulation Distortion: -25 DBC; (10)Gain Variation: 0 to 4 DB.

Features

RA03M4547MD features: (1)Enhancement-Mode MOSFET Transistors (IDD0 @ VDD=7.2V, VGG=0V); (2)Pout>38dBm @ VDD=7.2V, Pin=19dBm; (3)Idq1=30mA(Vgg1adjust.),Idq2=1A(Vgg2 adjust.); (4)ηT>34% @ VDD=7.2V, Pout=38dBm (Pin adjust.), Idq1=30m (Vgg1 adjust.),Idq2=1A(Vgg2 adjust.); (5)IMD3<-25dBc @ VDD=7.2V, Pout (average) =35dBm(Pin adjust.) Two tone test at 1KHz separation,Idq1=30mA(Vgg1 adjust.),Idq2=1A; (6)Broadband Frequency Range: 450-470MHz; (7)Low-Power Adjust. Current IGG=1mA (typ) at VGG=3.5V; (8)Module Size: 30 × 10 × 5.4 mm.
