RT8105GS

rt8105gs, advanced DC/DC synchronous buck PWM controller, 42V, 1.47W, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.30~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 500 :	2.40 / Piece
501 ~ 1000 :	2.30 / Piece

PartNumber:: RT8105GS

Brand:: Richtek Technology Corporation - richtek | Pack: | D/C:

Availability:: Supply Ability: 8000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-18

From Other Seller

Part Number:RT8105GS
US $2.30 - 2.50
Quantity:

piece

Product Summary

The rt8105gs is an advanced DC/DC synchronous buck PWM controller with several innovative functions for specific customer s ASIC only. The part features RichTek s innovative design and topology say “analogous current modefor current sensing and full functions for various applications including adjustable soft start, free-run and adjustable operation frequency and enable; the part is with design of 12V+12V boot strapped driver which is capable to drive up to 20Amp output current; moreover the part is with implementation of accuracy DCR current sensing topology. There are several specific features implemented and reserved for the specific customer’ s special applications including dual VCORE control mode including tracking and stand-alone mode, and output current indication. It is ideal for: (1)MB memory and chipset core power; (2)Middle-high graphic card GPU and memory core power; (3)General-purpose fields including server, NB, bare-bone and mini-system.

Parametrics

rt8105gs absolute maximum ratings: (1)Supply Voltage, VCC: 16V; (2)BOOT, VBOOT - VPHASE: 16V; (3)PHASE to GND DC: 5V to 15V;< 200ns: 10V to 30V; (4)BOOT to PHASE: 15V; (5)BOOT to GND DC: 0.3V to VCC+15V; < 200ns: 0.3V to 42V; (6)UGATE VPHASE: - 0.3V to VBOOT + 0.3V; (7)LGATE GND: - 0.3V to VCC + 0.3V; (8)Input, Output or I/O Voltage: GND-0.3V to 7V; (9)Power Dissipation, PD @ TA = 25°C VQFN-16L 3x3: 1.47W; (10)Package Thermal Resistance (Note 4)VQFN-16L 3x3, θJA: 68°C/W; (11)Junction Temperature : 150°C; (12)Lead Temperature (Soldering, 10 sec.): 260°C; (13)Storage Temperature Range : 65°C to 150°C; (14)ESD Susceptibility (Note 2)HBM (Human Body Mode): 1.5kV; MM (Machine Mode): - 150V.

Features

rt8105gs features: (1)Analogous Current Mode Design; (2)2.5V to 12V Switching Source Power; (3)0.8V to 3.3V Output Voltage Regulation; (4)Adjustable VIN Feed-Forward Ramp Slope; (5)Adjustable Operation Frequency; (6)Precise Core Voltage Regulation; (7)Precise DCR Current Sensing with High Quality Capacitor, X7R; (8) 1.5% System Accuracy; (9)Input Voltage : 12V and 5V Bias; (10)Enable Function; (11)RoHS Compliant and 100% Lead (Pb)-Free; (12)Over Current Protection; (13)External Soft Start Setting.
