Product Summary

The ss495a1 is a solid state sensors miniature ratiometric linear. The ss495a1 has a ratiometric output voltage, set by the supply voltage. It varies in proportion to the strength of the magnetic field.

Parametrics

SS495A1 absolute maximum ratings: 1)Supply Voltage, DC: 4.5 to 10.5 ma; (2)Supply Current ＠ 25℃: 7.0 ma; (3)Temperature Error: ±0.048%.

Features

SS495A1 features: (1)Small size (.160 × 118N); (2)Low power consumption - typically 7mAat5VDC; (3)Single current sinking or current sourcing linear output; (4)Built-in thin-film resistors - laser trimmed for precise sensitivity and temperature compensation; (5)Rail-to-rail operation provides more useable signal for higher accuracy; (6)Operating temperature range of –40 to +150℃; (7)Responds to either positive or negative gauss; (8)Quad Hall sensing element for stable output.

Diagrams

ss495a1 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
SS495A1
SS495A1
Honeywell
Board Mount Hall Effect / Magnetic Sensors 10mA 5V/9V 3-Pin
Data Sheet
0-1: $1.90
1-10: $1.64
10-50: $1.43
50-100: $1.28
SS495A1-L
SS495A1-L
Honeywell
Board Mount Hall Effect / Magnetic Sensors COMM SOLID STATE/MAG
Data Sheet
0-1: $3.54
1-10: $3.02
10-100: $2.87
100-250: $2.72
SS495A1-S
SS495A1-S
Honeywell
Board Mount Hall Effect / Magnetic Sensors COMM SOLID STATE/MAG Integ Cir Device
Data Sheet
0-725: $1.40
SS495A1-SP
SS495A1-SP
Honeywell
Board Mount Hall Effect / Magnetic Sensors Mini Ratiometric Hall-Effect Sensor
Data Sheet
0-740: $1.46
740-1000: $1.42
1000-2000: $1.38
2000-5000: $1.33
SS495A1-T3
SS495A1-T3
Honeywell
Board Mount Hall Effect / Magnetic Sensors Commercial SS/Magnet INTEG CIR DEVICE
Data Sheet
0-3850: $1.11
