Product Summary

The TMCTXE1C336KTRF is a tantalum electrolytic capacitor.

Parametrics

TMCTXE1C336KTRF absolute maximum ratings: (1)Operating temperature range: –55°C to +125°C; (2)Rated voltage DC: 10 to 35V; (3)Surge voltage DC: 13 to 45V; (4)Derated voltage DC: 6.3 to 22V; (5)Capacitance: 1 to 68μF; (6)Capacitance tolerance: ±10% or 20%.

Features

TMCTXE1C336KTRF features: (1)Protective-device-incorporated chip tantalum capacitor which is obtained by adding a thermal fuse to the TMC type; (2)High heat resistance: Withstands infra-red-reflow and solder dip and high reliability; (3)Prevention of fire or smoke with the work of internal fuse: Fusing characteristics: B, C cases: Open in less than 100 sec at 1.5 A or in less than 5 sec at 5 A; E, F cases: Open in less than 5 sec at 5 A.

Diagrams

TMCTXE1C336KTRF pin connection
