XTR105PA

two-wire current transmitter, 20mA, 36V, SOIC/DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.20~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	2.50 / Piece
101 ~ 800 :	2.40 / Piece
801 ~ 1600 :	2.20 / Piece

PartNumber:: XTR105PA

Brand:: Texas Instruments - TI | Pack: | D/C:

Availability:: Supply Ability: 8000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-23

From Other Seller

Part Number:XTR105PA
US $2.20 - 2.50
Quantity:

piece

Product Summary

The xtr105pa is a monolithic 4-20mA, two-wire current transmitter with two precision current sources. The xtr105pa provides complete current excitation for Platinum RTD temperature sensors and bridges, instrumentation amplifier, and current output circuitry on a single integrated circuit. The xtr105pa is available in 14-pin plastic DIP and SO-14 surface-mount packages and is specified for the -40°C to +85°C industrial temperature range. Applications of the xtr105pa include: industrial process control, factory automation, SCADA remote data acquisition and remote temperature and pressure transducers.

Parametrics

xtr105pa absolute maximum ratings: (1) Power Supply, V+ (referenced to Io pin) : 40V; (2) Input Voltage, VIN+, VIN- (referenced to Io pin) : 0 to V+; (3)Storage Temperature Range: -55 to +125°C; (4) Lead Temperature (soldering, 10s) : +300°C; (5) Output Current Limit: Continuous; (6) Junction Temperature: +165°C.

Features

xtr105pa features: (1) low unadjusted error; (2) two precision current sources 800μA each; (3) RTD or bridge excitation; (4) linearization; (5) two or three-wire RTD operation; (6) low offest drift: 0.4μV/°C; (7) low output current noise: 30nAp-p; (8) high PSR: 110dB min; (9) high CMR: 86dB min; (10) wide supply range: 7.5 to 36V; (11) 14-pin DIP and SO-14 SOIC packages.
