Product Summary

The BCP53-16 is a PNP Silicon AF Transistor.

Parametrics

BCP53-16 absolute maximum ratings: (1)Collector-emitter voltage: 80V; (2)Collector-base voltage: 100V; (3)Emitter-base voltage: 5V; (4)Collector current: 1A; (5)Peak collector current, tp ≤ 10 ms: 1.5A; (6)Base current: 100mA; (7)Peak base current: 200mA; (8)Total power dissipation- TS ≤ 120℃: 2W; (9)Junction temperature: 150℃; (10)Storage temperature: -65℃ to 150℃.

Features

BCP53-16 features: (1)For AF driver and output stages; (2)High collector current; (3)Low collector-emitter saturation voltage; (4)Complementary types: BCP54 to BCP56 (NPN); (5)Pb-free (RoHS compliant) package1); (6)Qualified according AEC Q101.

Diagrams

BCP53-16 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
BCP53-16
BCP53-16
STMicroelectronics
Transistors Bipolar (BJT) PNP Medium Power
Data Sheet
0-4000: $0.11
BCP53-16 /T3
BCP53-16 /T3
NXP Semiconductors
Transistors Bipolar (BJT) TRANS MED PWR TAPE13
Data Sheet
Negotiable
BCP53-16 T/R
BCP53-16 T/R
NXP Semiconductors
Transistors Bipolar (BJT) TRANS MED PWR TAPE-7
Data Sheet
Negotiable
BCP53-16,115
BCP53-16,115
NXP Semiconductors
Transistors Bipolar (BJT) TRANS MED PWR TAPE-7
Data Sheet
0-1: $0.05
1-25: $0.05
25-100: $0.04
100-250: $0.04
BCP53-16,135
BCP53-16,135
NXP Semiconductors
Transistors Bipolar (BJT) TRANS MED PWR TAPE13
Data Sheet
0-1: $0.06
1-25: $0.05
25-100: $0.05
100-250: $0.05
BCP53-16T1
BCP53-16T1
ON Semiconductor
Transistors Bipolar (BJT) 1.5A 100V PNP
Data Sheet
Negotiable
BCP53-16T1G
BCP53-16T1G
ON Semiconductor
Transistors Bipolar (BJT) 1.5A 100V PNP
Data Sheet
0-1: $0.29
1-25: $0.17
25-100: $0.14
100-500: $0.08
500-1000: $0.06
BCP53-16T3
BCP53-16T3
ON Semiconductor
Transistors Bipolar (BJT) SS GP XSTR PNP 80V
Data Sheet
Negotiable
