BTA08-600BRG

BTA08-600BRG, logic level and standard Triac, TO, 600V, 8A, STMicroelectronics

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.20~0.30 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.20~0.30

PartNumber:: BTA08-600BRG

Brand:: STMicroelectronics - ST | Pack: TO | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Dannie's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-10-29

From Other Seller

Part Number:BTA08-600BRG
US $0.20 - 0.30
SIL9030CTU

US $2.50 - 5.10 / Piece
(0) Remove
TOP259EN

US $1.10 - 3.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The BTA08-600BRG is a Snubberless, logic level and standard Triac. Available either in through-hole or surface-mount packages, the BTA08-600BRG triac is suitable for general purpose AC switching. It can be used as an ON/OFF function in applications such as static relays, heating regulation, induction motor starting circuits or for phase control operation in light dimmers, motor speed controllers.

Parametrics

BTA08-600BRG absolute maximum ratings: (1)On-state rms current (full sine wave), IPAK/D2PAK/DPAK/TO-220AB, Tc = 110℃, IT(RMS): 8 A; TO-220AB Ins. Tc = 100℃, IT(RMS): 8A; (2)Non repetitive surge peak on-state current, F = 50 Hz t = 20 ms, ITSM: 80A; F = 60 Hz t = 16.7 ms, ITSM: 84A; (3)I2t value for fusing tp = 10 ms, I2t: 36 A2s; (4)Critical rate of rise of on-state current IG = 2, F = 120 Hz, Tj = 125℃, dI/dt: 50 A/μs; (5)Peak gate current, tp = 20 μs Tj = 125℃, IGM: 4 A; (6)Average gate power dissipation, Tj = 125℃, PG(AV): 1 W; (7)Storage junction temperature range, Tstg: -40 to + 150℃; (8)Operating junction temperature range, Tj: -40 to + 125℃.

Features

BTA08-600BRG features: (1)On-state rms current, IT(RMS) 8 A; (2)Repetitive peak off-state voltage, VDRM/VRRM 600 to 800 V; (3)Triggering gate current, IGT (Q1) 5 to 50 mA.
