CAT24C02WI-GT3A

CAT24C02WI-GT3A, 2-Kb I2C CMOS Serial EEPROM, soic, 6.5V, 1mA, Catalyst Semiconductor inc

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.10~0.30 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.10~0.30

PartNumber:: CAT24C02WI-GT3A

Brand:: Catalyst Semiconductor inc - CSI | Pack: SOIC | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Dannie's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-11-09

From Other Seller

Part Number:CAT24C02WI-GT3A
US $0.10 - 0.30
ad7716ap

US $1.13 - 1.13 / Piece
(0) Remove
2DI75D-050A

US $16.00 - 30.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The CAT24C02WI-GT3A is a 2-Kb respectively CMOS Serial EEPROM organized internally as 16 and 128 pages respectively of 16 bytes each. The CAT24C02WI-GT3A supports both the Standard (100 kHz) as well as Fast (400 kHz) I2C protocol. Data is written by providing a starting address, then loading 1 to 16 contiguous bytes into a Page Write Buffer, and then writing all data to non-volatile memory in one internal write cycle. Data is read by providing a starting address and then shifting out data serially while automatically incrementing the internal address count.

Parametrics

CAT24C02WI-GT3A absolute maximum ratings: (1)Storage Temperature: -65 to +150℃; (2)Voltage on any pin with respect to Ground: -0.5 to +6.5 V.

Features

CAT24C02WI-GT3A features: (1)Supports Standard and Fast I2C Protocol; (2)1.7 V to 5.5 V Supply Voltage Range; (3)16-Byte Page Write Buffer; (4)Hardware Write Protection for Entire Memory; (5)Schmitt Triggers and Noise Suppression Filters on I2C Bus Inputs (SCL and SDA); (6)Low power CMOS Technology; (7)1,000,000 Program/Erase Cycles; (8)100 Year Data Retention; (9)Industrial and Extended Temperature Range; (10)These Devices are Pb-Free, Halogen Free/BFR Free and are RoHS Compliant.
