ICL3243ECVZ

ICL3243ECVZ, RS-232 transmitter/receiver, 6V, 250kbps, 1μA, TSSOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $8.00~10.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 500 :	10.00 / Piece
501 ~ 1000 :	9.00 / Piece
1001 ~ 5000 :	8.00 / Piece

PartNumber:: ICL3243ECVZ

Brand:: Intersil Corporation - Intersil | Pack: TSSOP | D/C: 13+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-12

From Other Seller

Part Number:ICL3243ECVZ
US $8.00 - 10.00
Quantity:

piece

Product Summary

The ICL3243ECVZ is a 3.0V to 5.5V powered RS-232 transmitter/receiver which meet ElA/TIA-232 and V.28/V.24 specifications, even at VCC = 3.0V. Additionally, the ICL3243ECVZ provides ±15kV ESD protection on transmitter outputs and receiver inputs. Targeted applications of the ICL3243ECVZ are PDAs, Palmtops, and notebook and laptop computers where the low operational, and even lower standby, power consumption is critical.. The ICL3243ECVZ is fully compatible with 3.3V-only systems, mixed 3.3V and 5.0V systems, and 5.0V-only systems.

Parametrics

ICL3243ECVZ absolute maximum ratings: (1)VCC to GND: -0.3V to 6V; (2)V+ to GND: -0.3V to 7V; (3)V- to GND: +0.3V to -7V; (4)V+ to V-: 14V; (5)Input Voltages, TIN, FORCEOFF, FORCEON, EN, SHDN: -0.3V to 6V; (6)RIN: ±25V; (7)Output Voltages, TOUT: ±13.2V; (8)ROUT, INVALID: -0.3V to VCC +0.3V; (9)Short Circuit Duration, TOUT: Continuous.

Features

ICL3243ECVZ features: (1)ESD Protection for RS-232 I/O Pins to ±15kV; (2)Drop in Replacements for MAX3221E, MAX3222E, MAX3223E, MAX3232E, MAX3241E, MAX3243E, SP3243E; (3)ICL3221E is a Low Power, Pin Compatible Upgrade for 5V MAX221E; (4)ICL3222E is a Low Power, Pin Compatible Upgrade for 5V MAX242E, and SP312E; (5)ICL3232E is a Low Power Upgrade for HIN232E, ICL232 and Pin Compatible Competitor Devices; (6)RS-232 Compatible with VCC = 2.7V; (7)Meets EIA/TIA-232 and V.28/V.24 Specifications at 3V; (8)Latch-Up Free; (9)On-Chip Voltage Converters Require Only Four External 0.1μF Capacitors; (10)Manual and Automatic Power-Down Features; (11)Guaranteed Mouse Driveability (ICL324xE Only); (12)Receiver Hysteresis For Improved Noise Immunity; (13)Guaranteed Minimum Data Rate: 250kbps; (14)Wide Power Supply Range: Single +3V to +5.5V; (15)Low Supply Current in Power-Down State: 1μA; (16)Pb-Free Available (RoHS Compliant).
