Product Summary
The IRFB3306PBF is a HEXFET Power MOSFET. The applications of the include High Efficiency Synchronous Rectification in SMPS, Uninterruptible Power Supply, High Speed Power Switching, Hard Switched and High Frequency Circuits.
Parametrics
IRFB3306PBF absolute maximum ratings: (1)ID @ TC = 25℃, Continuous Drain Current, VGS @ 10V: 160 A; (2)ID @ TC = 100℃, Continuous Drain Current, VGS @ 10V: 110A; (3)IDM, Pulsed Drain Current: 620A; (4)PD @TC = 25℃, Maximum Power Dissipation: 230 W; (5)Linear Derating Factor: 1.5 W/℃; (6)VGS, Gate-to-Source Voltage: ±20V; (7)dv/dt, Peak Diode Recovery: 14 V/ns; (8)TJ,TSTG, Operating Junction and Storage Temperature Range: -55 to 175℃; (9)Soldering Temperature, for 10 seconds (1.6mm from case): 300; (10)Mounting torque, 6-32 or M3 screw: 10lb·in (1.1N·m).
Features
IRFB3306PBF features: (1)Improved Gate, Avalanche and Dynamic dV/dt Ruggedness; (2)Fully Characterized Capacitance and Avalanche SOA; (3)Enhanced body diode dV/dt and dI/dt Capability; (4)Lead-Free.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 IRFB3306PBF |
International Rectifier |
MOSFET MOSFT 60V 160A 4.2mOhm 85nC Qg |
Data Sheet |
|
|
||||||||||||
