T6816

T6816, protected driver, 40 V, 1.4 A, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 500 :	3.00 / Piece
501 ~ 1000 :	2.00 / Piece
1001 ~ 3000 :	1.00 / Piece

PartNumber:: T6816

Brand:: ATMEL Corporation - Atmel | Pack: SOP | D/C: 13+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Dannie's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-13

From Other Seller

Part Number:T6816
US $1.00 - 3.00
Quantity:

piece

Product Summary

The T6816 is a fully protected driver interface designed in 0.8 μm BCDMOS technology. The T6816 is especially suitable for truck or bus applications and the industrial 24-V supply. The T6816 controls up to 12 different loads via a 16-bit dataword. Each of the six high-side and six low-side drivers is capable to drive currents up to 600 mA. The T6816 freely configurable and can be controlled separately from a standard serial data interface. Therefore, all kinds of loads such as bulbs, resistors, capacitors and inductors can be combined. The T6816 is also designed to easily build Hbridges to drive DC motors in motion-control applications.

Parametrics

T6816 absolute maximum ratings: (1)Supply voltage Pins 5, 10 VVS: -0.3 to +40 V; (2)Supply voltage tt0.5 s; ISu-2 A Pins 5, 10 VVS: -1 V; (3)Supply voltage difference |VS_Pin5 - VS_Pin10| DVVS: 150 mV; (4)Supply current Pins 5, 10 IVS: 1.4 A; (5)Supply current t < 200 ms Pins 5, 10 IVS: 2.6 A; (6)Logic supply voltage Pin 19 VVCC: -0.3 to +7 V; (7)Input voltage Pin 17 VINH: -0.3 to +17 V; (8)Logic input voltage Pins 24 to 26 VDI, VCLK, VCS: -0.3 to VVCC +0.3 V; (9)Logic output voltage Pin 18 VDO: -0.3 to VVCC +0.3 V; (10)Input current Pins 17, 24 to 26 IINH, IDI, ICLK, ICS: -10 to +10 mA; (11)Output current Pin 18 IDO: -10 to +10 mA; (12)Junction temperature range Tj: -40 to +150°C; (13)Storage temperature range TSTG: -55 to +150°C.

Features

T6816 features: (1)Six High-side and Six Low-side Drivers; (2)Outputs Freely Configurable as Switch, Half Bridge or H–bridge; (3)Capable to Switch all Kinds of Loads such as DC Motors, Bulbs, Resistors, Capacitors and Inductors; (4)0.6 A Continuous Current per Switch; (5)Low-side: RDSon < 1.5 versus Total Temperature Range; (6)High-side: RDSon < 2.0 versus Total Temperature Range; (7)Very Low Quiescent Current Is < 20 μA in Standby Mode; (8)Outputs Short-circuit Protected; (9)Overtemperature Prewarning and Protection; (10)Undervoltage Protection; (11)Various Diagnosis Functions such as Shorted Output, Open Load, Overtemperature and Power Supply Fail; (12)Serial Data Interface; (13)Operation Voltage up to 40 V; (14)Daisy Chaining Possible; (15)SO28 Power Package.
