Product Summary

The TBA820M is a monolithic integrated audio amplifier. It is designed for audio frequency class b amplifier.

Parametrics

TBA820M absolute maximum ratings: (1)Supply Voltage, Vcc: 16 V; (2)Output Peak Current, IO(peak): 1.5 A; (3)Power Dissipation, PD: 1.25 W; (4)Operating Temperature, TOPR: 0 to +70℃; (5)Storage Temperature, TSTG: -40 to +150℃.

Features

TBA820M features: (1)Wide operating supply voltage: Vcc= 3 to 14V; (2)Medium output power, POUT=1.2W at Vcc= 9V,RL= 8Ω, THD= 10%; (3)Low quiescent circuit current: IQ=4mA(type); (4)Good ripple rejection; (5)Minimum number of external parts required.
