Product Summary
The XC6SLX16 is an Initiator/Target core for PCI. It is a pre-implemented and fully tested module for Xilinx FPGAs. The pinout for each device and the relative placement of the internal logic are predefined. Critical paths are controlled by constraints files to ensure predictable timing, significantly reducing the engineering time required to implement your design. The applications of the XC6SLX16 include Embedded applications in networking, industrial, and telecommunication systems, Add-in for PCI boards such as frame buffers, network adapters, and data acquisition boards, Hot swap CompactPCI boards, CardBus compliant and Any application requiring a PCI interface.
Parametrics
XC6SLX16 absolute maximum ratings: (1)VCCINT, Internal supply voltage relative to GND: –0.5 to 1.32 V; (2)VCCAUX, Auxiliary supply voltage relative to GND: –0.5 to 3.75 V; (3)VCCO, Output drivers supply voltage relative to GND: –0.5 to 3.75 V; (4)VBATT, Key memory battery backup supply: –0.5 to 4.05 V; (5)VFS, External voltage supply for eFUSE programming: –0.5 to 3.75 V.
Features
XC6SLX16 features: (1)Fully compliant 64-bit, 66/33 MHz LogiCORE IP Initiator/Target core for PCI; (2)Customizable, programmable, single-chip solution; (3)Pre-defined implementation for predictable timing; (4)Incorporates Xilinx Smart-IP? technology; (5)3.3V operation at 0–66 MHz; (6)5.0V operation at 0–33 MHz; (7)Fully verified design tested with Xilinx proprietary test bench and hardware; (8)Delivered through Xilinx CORE Generator software; (9)CardBus compliant.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 XC6SLX16-2CPG196C |
|
IC FPGA SPARTAN 6 14K 196CPGBGA |
Data Sheet |
|
|
||||||
 |
XC6SLX16-2CPG196I |
|
IC FPGA SPARTAN 6 14K 196CPGBGA |
Data Sheet |
|
|
||||||
|
XC6SLX16-2CSG225C |
|
IC FPGA SPARTAN 6 14K 225CSGBGA |
Data Sheet |
|
|
||||||
|
XC6SLX16-2CSG225I |
|
IC FPGA SPARTAN 6 14K 225CSGBGA |
Data Sheet |
|
|
||||||
|
XC6SLX16-2CSG324C |
|
IC FPGA SPARTAN 6 14K 324CSGBGA |
Data Sheet |
|
|
||||||
|
XC6SLX16-2CSG324CES |
|
IC FPGA SPARTAN 6 15K 324CSBGA |
Data Sheet |
Negotiable |
|
||||||
|
XC6SLX16-3CSG225C |
|
IC FPGA SPARTAN 6 14K 225CSGBGA |
Data Sheet |
|
|
||||||
|
XC6SLX16-2CSG324I |
|
IC FPGA SPARTAN 6 14K 324CSGBGA |
Data Sheet |
|
|
||||||
