Product Summary
The b1205xt-1wr2 is a 1W, fixed input, isolated & unregulated single output, which is designed for application where isolated output is required from a distributed power system. The b1205xt-1wr2 applies to Input voltage variation ≤ ±10%, 1.5KVDC input and output isolation and Regulated and low ripple noise is not required. Such as: digital circuits, low frequency analog circuits, and IGBT power device driving circuits.
Parametrics
b1205xt-1wr2 absolute maximum ratings: (1)Input Voltage: 12VDC; (2)Output Voltage: 5VDC; (3)Efficiency @Max. Load: 80%, Typ.; (4)Output Current: 200mA; (5)Input Current: 104mA; (6)Reflected Ripple Current: 5mA; (7)Max. Capacitive Load: 220μF.
Features
b1205xt-1wr2 features: (1)Small Footprint; (2)SMD Package Style; (3)1500VDC Isolation; (4)Operating Temperature Range: -40℃～+105℃; (5)Low Temperature rise; (6)Internal SMD construction; (7)No External Component Required; (8)Industry Standard Pinout.
Diagrams
