Product Summary
The cd0402-t05c is a TVS Diode Array. It offers a choice of voltage types ranging from 3 V to 36 V in a bidirectional configuration. It conforms to JEDEC standards, is easy to handle on standard pick and place equipment and their flat configuration minimizes roll away. The cd0402-t05c will meet IEC 61000-4-2 (ESD), IEC 61000-4-4 (EFT) and IEC 61000-4-5 (Surge) requirements.
Parametrics
cd0402-t05c absolute maximum ratings: (1)Peak Pulse Power (tp = 8/20 μs) PPP: 250 W; (2)Operating Temperature TJ: -55 ℃ to 150 ℃; (3)Storage Temperature TSTG: -55 ℃ to 150 ℃; (4)Min. Breakdown Voltage @ 1 mA VBR: 6.0 V; (5)Working Peak Voltage VWM: 5.0 V; (6)Maximum Clamping Voltage @ IP2 VF: 11.0 V; (7)Maximum Clamping Voltage @ 8/20 μs VC @ IPP2 VF: 14.7 V @ 17 A; (8)Maximum Leakage Current @ VWM ID: 10 ∧ 4 μA; (9)Typical Capacitance @ 0 V, 1 MHz C: 100 pF.
Features
cd0402-t05c features: (1)Lead free as standard; (2)RoHS compliant; (3)Protects 1 line; (4)Bidirectional configuration; (5)ESD protection.
